Automatic 100-1500 pcs/h detergent bottle blowing machine

Specifications

detergent bottle blowing machine
1.different models
2.Capacity from 100-1500 pcs per hour

detergent bottle blowing machine

1.different models

2.Capacity from 100-1500 pcs per hour

Automatic 100-1500 pcs/h detergent bottle blowing machine Automatic bottle blow molding machine has simple operation, compact structure and stable design. It is suitable for small volume, many kinds of bottles, and it insludes drinks bottle, medicine bottles and plastic barrel and edible oil bottle and domestic bottle. They are based on PE, PP, PVCas raw materials.

This machine has man-machine operation screen to adjust and control as time to control stablility and safty.

Technical parameters:

Model	LD	Sxale of using	PA,PC,PE,PS,PVC,PP
Capacity	230kg/h	Dia of screw stem	55mm
Width of blowing	365	Motor	5.5kw
Design	Yes	mar open daylight	300mm
Thickness of forming product	1mm	minimum clamping distance	70mm

Series of bottle blow molding machine

Model	Scale of using	volumem(WLH M)	Capacity h	Mold volume (mm)	Remarks
LD-110	0.5ml--500ml	0.5*1.2*1.1	800-1500	60--110	Pneumatic dual-mode
LD-130	100ml--500ml	0.5*1.3*1.1	800-1300	60--120	Pneumatic dual-mode
LD-140	100ml-1000ml	0.5*1.481.1	600-1200	70--140	Pneumatic dual-mode
LD-150	100ml--1L	0.5*1.5*1.1	100-1500	70--150	Pneumatic dual-mode
LD-170	300ML-1L	0.5*1.7*1.1	800-1200	80--170	Pneumatic dual-mode
LD-200	500ML-2L	0.8*1.3*1.5	600-1000	80--200	Pneumatic dual-mode

This machine has the following several features:

A, consumption process all complete automation, saving investment, high efficiency and lunch, simple maintenance and safe operation etc;

B, walks machine automatically send blank;

C, the cooling effect of cooling system to reach the ideal;

D, the tubes in the heating, reflex plate width and height can regulate, with appropriate bottle of billet heating of different structure, and has installed automatic exhaust temperature, to ensure that the path of constant temperature;

E every mechanical action, bottle blowing machine has safe self-locking installation, when rendering a process problem, the program will automatically LDitch to the safe state;

F, each action is driven by cylinder, do not use the oil pump, has no pollution, low noise advantages;

G, bottle scrap rate lower than 0.2%;

H, the adoption of high pressure and hyperbolic arm connecting rod clamping, strong clamping force;

I, operation manual and automatic two ways;

J, safe reliable valve position design together, is to let gas path became like the palm of his hand;

K, bottle blowing machine movements and blowing gas path design divided into three parts, in order to meet the needs of bottle blowing, action of different pressure.

L, bottles from pollution

M, using infrared light tube heating, strong penetrating power, bottle preform rotation is heated, orbit, average heating, fast reliable;

N, adopts advanced microcomputer control system, stable performance

O, installation, start simple

Main picture

Remarks

Ⅰ.Delivery time: 20 days after receiving the whole payment.

Ⅱ.Payment term: 100% in advance by T/T

III. Valid time : This quotation is valid for one month.

IV .Quality Guarantee Terms:

Quality guarantee term is for one year(exclude wearable spare parts) . Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self
